DPH390 | High-Volume Rotary
When raw capacity and massive throughput are the primary goals, the DPH390 delivers. Featuring an unprecedented 390mm web width—the widest in our rotary blister packaging lineup—this robust machine is engineered specifically to handle ultra-high volume mass production. To accommodate different investment scales, it is available in a highly cost-effective mechanical drive version for tight budgets, as well as a full-servo configuration that adds operational flexibility to its massive output.
Built as a reliable production workhorse, the DPH390 features a cGMP-compliant balcony (cantilever) architecture that strictly isolates drive mechanisms from the operating zone to prevent cross-contamination. To maximize continuous production, it accommodates large 600mm forming reels and includes an integrated splicer, with optional auto-splicing available for zero-downtime manufacturing. Combined with a format positioning mechanism and a material-saving low-waste trimming cutter, it is designed to maximize overall equipment effectiveness (OEE) while minimizing waste.
| Max. Speed: | 200 punches/min. |
| Max. Output: | 800 blisters/min. ( blister size 57×90mm) |
| Max. Forming Area: | 380×250mm |
| Material Max. width: | 390 mm |
| Machine Power: | 16.7kw |
| Machine Dimension: | 5300mm×1250mm×2000mm |
| Machine Weight: | 3200kg |
Blister Pack & Blister Packaging Machine Guide
Blister packaging remains an essential process in the pharmaceutical industry for unit-dose solid medications, with production methodologies split between thermoforming and cold-forming systems.
Classification of these packaging lines largely depends on their motion kinematics and sealing mechanisms: intermittent-motion platen configurations rely on precision plate-to-plate stamping for high-flatness sealing, while continuous-motion rotary setups utilize revolving roller dies to achieve exceptionally high output rates for large-volume batch production.
