Cartoning Machine ZH200
The ZH200 is a highly stable, continuous-motion cartoning machine engineered to deliver exceptional performance for medium-batch production. Built upon a cGMP-compliant cantilever (balcony) architecture, this space-saving system strictly isolates the operational zone from the mechanical drive, ensuring optimal accessibility for daily cleaning and maintenance.
Designed for maximum versatility, the ZH200 effortlessly handles a wide spectrum of products, including blister cards, bottles, and parenteral packaging. From automatic leaflet folding and rotary carton feeding to precise product insertion and final discharge, the machine fully automates the cartoning process while integrating seamlessly into comprehensive packaging lines.
Continuous Motion: Compact and space-saving, ideal for medium batches.
Wide Applicability: Cartons blister cards, bottles, and parenteral products.
Rotary Pick & Place: Efficiently extracts and opens cartons via rotary feeder.
Leaflet Folding: Integrated device folds leaflets 1-4 times.
High Capacity: Extended magazine holds ~1,000 cartons.
Position Indicators: Digital displays ensure straightforward adjustments.
Smart Setup: Optional servo positioning for recipe-based smart changeovers.
Balcony Design: Cantilever structure simplifies daily cleaning and maintenance.
Versatile Cartoning Applications
Inside the magazine, the blister cards are counted when they free fall via the servo-motor, and are then held in position by the transfer belt.
The Leaflet Folding Device can adopt GUK or MB Leaflet Folder (optional).
The Leaflet are isolated from the bottom from a pile magazine, then pulled off and folded. It can make the leaflet fold one to four folds according to customer’s demand.
Adopt long carton magazine for approximately 1000 cartons.
Rotary carton feeder can sucks the cartons from the carton magazine, open the carton, place it on the carton conveyor.
The inserter device can push the blister cards into the carton in continuous motion.
The carton conveyor chain is used to transfer opened cartons to every stations, that can automatically complete the actions of inserting of blister cards and leaflets into cartons, embossing, closing of cartons, discharging of carton
At the end of the Carton Conveyor the cartons are discharged.
| Max.Output: | 200 cartons/min. |
| Range of Carton Size: | Max. 210x100x65 mm; Min. 65x30x17mm |
| Machine Power: | 4.2kw |
| Machine Dimension: | 3756x1610x1800mm |
| Machine Weight: | 3000kg |
